Product Model: RW-BV2C
Material: Brass + Stainless Steel
Color: As shown in the picture
Overall Dimensions: 250*100*167mm
Overall Weight: 1.35kg
Steam Engine Dimensions: 120*81.5*106mm
Steam Engine Weight: 600g
Displacement: 6cc (1.5cc*2*2)
Boiler Diameter: 12.2mm
Stroke: 12.7mm
Maximum Speed: 3000rpm
Maximum Torque: 1200g/cm²
Power: 0.03hp
Threaded Fittings: M7*0.75
Copper Boiler: Weight 700g, Capacity 200mL
Fuel: 95% Alcohol, Capacity 50mL
Working Pressure: 2 kg/cm²
Safety Valve Pressure: 2.5-3 kg/cm²
Pressure Gauge Range: 0-7 Bar (kg/cm²)
Suitable Boat Size: 70-130cm
Suitable Age: 16+
Packaging: Box
Package List: Steam Engine *1, Boiler *1, Base *1 set, Tool Set *1 set, Instruction Manual *1
Product Features:
1. Superior Materials, Robust and Durable: The engine body is constructed of high-strength die-cast brass with stainless steel cylinder liners, offering both wear resistance and corrosion resistance to ensure long-term stable operation. It supports real steam output, boasts a robust structure, and is safe and reliable in operation.
2. Precision Craftsmanship, Quality Assurance: Key components are machined with high-precision CNC. The piston is equipped with composite piston rings, and the crankshaft is supported by ball bearings, ensuring smooth operation and low wear. The brass body combined with a retro mechanical appearance offers both engineering quality and collectible appeal.
3. Innovative Design, Powerful Performance: A compact body packs powerful performance, balancing size and performance. It can be used as a model boat, teaching equipment, or a small mechanical power source. Its power performance far surpasses similar mini engines, showcasing the charm of high-efficiency engineering.
4. Flexible Operation, Reversible: Equipped with a classic Stephenson valve-controlled gas distribution system, it allows for free switching between forward and reverse rotation. Its compact structure, sensitive response, and simple operation significantly enhance operational flexibility and practicality, faithfully recreating the power logic of 19th-century steam machinery.
5. Smooth Operation, Collector's Choice: The machine is almost fully assembled, with the boiler equipped with multiple safety components including a pressure regulating valve, safety valve, pressure gauge, and water level gauge. It is an ideal collectible and display piece for engineers, mechanical model enthusiasts, students, and collectors.
